Five-axis Laser Cutting Machine For 3D Surfaces
This machine is specially designed to precisely cut complex shapes such as automotive body parts and dashboards and drill & trim 3D hot-forming metal workpieces, with high flexibility. As thus, automobile will be more light-weight and extend its endurance mileage.
N*360° Limitless rotation
±135° Swing
100 [m/min] Max no-load speed
If you have more questions to ask us and get best quote, please contact us now directly via WhatsApp or Email:
Technical Parameters
| Main Parameters | Model |
| SF3015TD | |
| Laser Power (kW) | 3 |
| Travel Range (L*W, mm) | 1064 |
| Max Pulse Energy (mJ) | 3000*1500 |
| X/Y-axis Positioning Accuracy (mm) | ±0.1 |
| X/Y-axis Repositioning Accuracy (mm) | ±0.05 |
| Max No-load Speed (m/min) | 100 |
| Max Acceleration (G) | 1 |
| Machine cooling | Air-cooled |
| A-axis Rotating Angle | ± 135° |
| C-axis Rotating Angle | N*360° |
| Overall Dimensions (L*W*H, mm) | 6000*2800*2755 |
| Power Supply | Three-phase 380V, 50Hz/60Hz (custom-made) |
Automation
Optional Benefits
1. Reserve expansion interface
Users may interconnect with other processing devices to expand to fully automatic production line
What is laser cutter and how does it work?
A laser cutter uses laser as heat source and can be classified as sheet cutting and tube cutting. This includes sheet laser cutter, tube laser cutter and sheet & tube combo, making it one of the most advanced metal processing equipment available today.
The laser cutter utilizes the high-density laser beam to convert laser energy into thermal energy, causing localized heating, melting or even vaporization of materials. The melted or vaporized material is then blown away by using gas flow or other methods to achieve cutting.
The power of a fiber laser directly impacts its cutting capabilities. Fiber lasers with different power levels are suitable for various material thicknesses and types. The following article provides an overview of the cutting capabilities for the main power ranges: Cutting Capacity and Speed of 1.5kW-80kW Fiber Lasers
