Panel Bender Machine with Automatic Tool Changer
The new panel bender employs multi-axis concurrent linkage and universal bending tools to bend thin metal sheets automatically. It also features automatic tool changer to further enhance its level of automation and reduce reliance on molds and workers, so as to improve bending efficiency and lower production costs.
1250 [mm] Max bending width
200 [mm] Max bending height
0.2 [S/bend] Max bending speed
If you have more questions to ask us and get best quote, please contact us now directly via WhatsApp or Email:
Technical Parameters
Model | BDC2500 |
Max Bending Speed (S/bend) | 0.2 |
Max Bending Length (mm) | 2500 |
Bending Height (mm) | 200 (or 175 when hinge cutter is used) |
Max Bending Thickness (mm) | 304 stainless steel: 1.5 |
Min Bending Thickness (mm) | 0.35 |
Max Bending Size (L*W, mm) | 2500*1250 |
Number of Axes | 23-axis concurrent linkage |
Overall Dimensions (L*W*H, mm) | 5700*5200*3050 |
Gross Mass (T) | 20 |
Automation
Optional Benefits
1. Intelligent interconnection
Reserve robot/truss expansion interface for loading & unloading, so as to make bending, loading & unloading fully automatic.
2. Increase bending height
Generally, this panel bender comes standard with 200mm bending height (or 175mm when hinge cutter is used), but users may apply for 300mm (or 275mm under conditions above) based on their actual requirements.
A press brake is a device that can bend thin sheet metals. It generates pressure through a hydraulic system, which is transmitted by upper and lower molds to achieve the desired bending shape. Depending on its drive mode, level of automation and structure, press brakes can be classified into manual, hydraulic and CNC press brakes.
Panel bender is a highly automated bending machine, representing the latest advancement in sheet metal bending. It can bend into various complex shapes such as right angle, arc, up and down, without the need for manual holding of workpiece or bending mold. One-time positioning is enough for multi-side bending. Its bending speed is about 3 times faster than traditional press brakes. Due to the fewest human intervention, the consistency among workpieces is much higher, and it is gradually replacing the tradition.
For the panel bender, workers only need to place workpieces on its worktable, then, the workpiece will be positioned by suction cup or press-down arm and bent automatically. A set of universal bending mold is enough, without frequent change or customization.
