Handheld Fiber Laser Welding Machine HWM Series
This handheld laser welding machine, with water cooling, is easy to operate and can work stably at high quality in complex environment. As for company owners in need, HWM can yet be regarded as a rewarding choice with small investment but large returns.
7 [mm] Max thickness of sheet
≤0.7 [kg] Weight of welding gun
10 [m] Max length of welding gun’s optical fiber
If you have more questions to ask us and get best quote, please contact us now directly via WhatsApp or Email:
Technical Parameters
| Main Parameters | Model | ||
| SF1500HWM | SF2000HWM | SF3000HWM | |
| Laser Power (kW) | 1.5 | 2 | 3 |
| Laser Wavelength (nm) | 1080±10 | 1080±10 | 1080±10 |
| Thickness of Welding Sheet (mm) | ≤4mm | ≤5mm | ≤7mm |
| Diameter of Filler Wire (mm) | 0.8-1.6 (standard) | 0.8-1.6 (standard) | 0.8-2 (standard) |
| Weight of Welding Gun (kg) | ≤0.7 | ≤0.7 | ≤0.7 |
| Length of Welding Gun Line (m) | 10 | 10 | 10 |
| Net Weight of Machine (kg) | 220 | 220 | 265 |
| Overall Dimensions (L*W*H, mm) | 954*715*1080 | 954*715*1080 | 1210*715*1080 |
| Power Supply | Three-phase 380V, 50Hz/60Hz (custom-made) | ||
Automation
Optional Benefits
1. Intelligent interconnection
I/O autorun interface is reserved to interconnect with welding robot by only pressing a button. We try to get it smarter and more automatic. With it, you will enjoy welding you never had before.
A laser welding machine is a device used for welding materials. It has a high power density and fast energy release, making its welding efficiency superior to other traditional welding patterns. Whether welding the same type or different materials, it is unnecessary to carry out secondary treatment. Its emergence has led to a large leap in welding technology.
Laser welding utilizes high-energy laser beam to locally heat small areas of materials. The energy from laser radiation quickly diffuses into the material through thermal conduction, melting the material to form a specific molten pool for welding purpose.
Currently, SENFENG can offer more than 10 kinds of different welding machines for customers worldwide. According to degree of automation, we have handheld and robot-assisted machines. Based on cooling mode, there are air-cooled and water-cooled types. With regard to heat source, laser welding and electric-arc welding are available now. Customers may make decision or apply for customization as needed.
