Portable Fiber Laser Welding Machine S Series
This new product is famous for its unique air-cooled heat dissipation and small structure. That is why it works flexibly, adapts to various workplaces quickly and needs much less costs of transport and storage space. Users will enjoy bran-new welding easily.
5 [mm] Max thickness of sheet
≤0.7 [kg] Weight of welding gun
7 [m] Max length of welding gun’s optical fiber
If you have more questions to ask us and get best quote, please contact us now directly via WhatsApp or Email:
Technical Parameters
| Main Parameters | Model | ||
| SF3S | SF4S | SF5S | |
| Laser Power (kW) | 0.8 | 1.2 | 1.5 |
| Laser Wavelength (nm) | 1080±10 | 1080±10 | 1080±10 |
| Thickness of Welding Sheet (mm) | 3mm | ≤4mm | ≤5mm |
| Diameter of Filler Wire (mm) | 0.8-1.6 (standard) | 0.8-1.6 (standard) | 0.8-1.6 (standard) |
| Weight of Welding Gun (kg) | ≤0.7 | ≤0.7 | ≤0.7 |
| Length of Welding Gun Line (m) | 5 | 7 | 7 |
| Net Weight of Machine (kg) | 45 | 50 | 55 |
| Overall Dimensions (L*W*H, mm) | 670*335*590 | 670*335*590 | 670*335*590 |
| Languages | 24 kinds of languages like Chinese, English, Korean, Russian, Japanese, German, French | ||
| Power Supply | Single-phase 220V, 50/60HZ | ||
Automation
Optional Benefits
1. Intelligent interconnection
I/O autorun interface is reserved to interconnect with welding robot by only pressing a button. We try to get it smarter and more automatic. With it, you will enjoy welding you never had before.
A laser welding machine is a device used for welding materials. It has a high power density and fast energy release, making its welding efficiency superior to other traditional welding patterns. Whether welding the same type or different materials, it is unnecessary to carry out secondary treatment. Its emergence has led to a large leap in welding technology.
Laser welding utilizes high-energy laser beam to locally heat small areas of materials. The energy from laser radiation quickly diffuses into the material through thermal conduction, melting the material to form a specific molten pool for welding purpose.
Currently, SENFENG can offer more than 10 kinds of different welding machines for customers worldwide. According to degree of automation, we have handheld and robot-assisted machines. Based on cooling mode, there are air-cooled and water-cooled types. With regard to heat source, laser welding and electric-arc welding are available now. Customers may make decision or apply for customization as needed.
